Description
This 130C9 sprocket is a 9 tooth cast construction sprocket with a C-Hub (hub on both sides). This sprocket is in the 130 series of engineer class sprockets. It can be supplied with a stock plain bore, finished bore with key-way and set screws, or as an idler sprocket configuration. This sprocket works with chain sizes WHT130/138, 131, 138, WH784, 130RT, 138RT, H130, H130 rooftop chain, H138, H138 rooftop chain, and WS784.
130C9 Dimensions
- Tooth Count: 9
- Style: C
- Pitch Diameter: 11.70″
- Hub Diameter: 5.75″
- Length Thru Bore: 3.00″
- Max Bore: 4.50″
- Tooth Face at Pitch Line: 1.000″
- Roller Diameter: 1.000″
- Weight: 33.0 LBS
USA Roller Chain and Sprockets always strives to provide the industry leading service we are known for, as well as competitive and fair prices. Besides sprockets we also offer a full line of roller and engineer class chains, motors with gear reducers, v-belts, pulleys, and a wide variety of other industrial power transmission products. For more information or to get a quote on 130C9 sprockets or any other products, please contact our customer support team and we will be happy to assist you.
