Description
CSB730MFM205-14 stamped steel bearing is a 2-bolt vibration-damping flush mount flange bearing designed for light-duty industrial and agricultural applications. The superior quality stamped steel housing encases a performance C3 precision 7/8″ insert bearing that utilises an eccentric locking collar for securing onto a shaft. The bearing unit features a rubber cushion made from high-quality rubber for decreasing vibration. CSB730MFM205-14 bearings are more economical than their cast counterparts but offer excellent performance in bearing applications; the two-bolt flange stamped steel housing allows for great mounting when the shaft is positioned perpendicular to the bearing. Utilizing two mounting holes, the CSB730MFM205-14 7/8″ bearing has incredible holding power, stability, and mounting position flexibility. Additionally, our CSB730MFM205-14 stamped steel bearing features a zinc plated housing for added protection against the elements in corrosive or outdoor applications. For more information or to get a quote on our flush mount CSB730MFM205-14 bearing, contact our customer support team, and we will be happy to assist you!
CSB730MFM205-14 Bearing Dimensions
- Bearing Unit Part #: CSB730MFM205-14
- Bearing I.D: 7/8″
- Dimension (a): 4-1/2″
- Dimension (e): 3-3/8″
- Dimension (b): 2-1/2″
- Dimension (D): 29/64″
- Dimension (E): 3/4″
- Dimension (Bi): 1.063″
- Bolt Size: 5/16″
- Bearing Part #: CSB205-14
- Housing With Rubber Insert Part #: 730-2-MFM
- Weight: 0.50 LBS
