Description
The XTB25 stainless steel bushing with a 1-15/16″ bore is explicitly designed for conveyor pulley applications. Our XTB25 stainless bushing with a 1-15/16″ bore was precision machined from high-quality 300-grade stainless steel, giving it the ability to operate in food-grade, abrasive, and corrosive applications. By design, this bushing style provides superior holding power when compared with other styles and utilizes a 2″ per foot taper. Additionally, our XTB25 stainless bushing with a 1-15/16″ bore is easier to install and remove with uniformly spaced bolts for easy draw-up. For additional information or a quote on our XTB25SS stainless steel bushing with a 1-15/16″ bore, contact our customer service team, and we will gladly assist you!
XTB25SS Bushing 1-15/16″ Bore Dimensions
- Bushing Size: XTB25SS
- Bore Size: 1-15/16″
- Dimension (L): 1-7/8″
- Dimension (U): 5/8″
- Dimension (H): 4-7/16″
- Dimension (S): 1/4″
- Cap Screws: 4 – 3/8″ X 1-3/4″
- Weight: 2.6 LBS
